Product information

Equipment:

Basic Equipment Inventhor 9:

• MTU Diesel engine 6R1300, 390 kW at 1.700 rpm complies with  EUROMOT V
• additional hdraulic connection 30 l/min and 70 l/min
• roller driven by planetary gear 380 kW -VARIO-
• load-Sensing -System
• 950 l fuel tank
• longitudinal conveyor: belt length 4450 mm, belt width 1000 mm
• central lubrication
• 24 V electric control
• additional electric pump for the following functions at engine standstill:"lift/lower/fold rear conveyor, open/close comb gate, open/close comb, lilft/lower
• optional premanent magnet belt lift/lower optional retractable hopper"
• remote control complete
• large GRP side doors for maintenance
• maintenance-friendly engine compartment with LED
• hydraulically reversible fan wheel
• loading protection on both sides
• fire extinguisher
• maintenance ladder
• tool box
• audible starting signal
• Doppstadt-Telematic-System
• paint RAL2011 deep orange

Additional Equipment:

• 3-Axle Semitrailer Unit
• Shredding system size “L-C3” - 42 teeth
• Size "L" - "Limiter"
• Hydraulic self- propelled drive
• watering with hopper extension both sides
• rear conveyor AA 8.5 m
• Overband magnet -Neodym-
• Magnet frame for overband magnet
• Central lubrication with pump
• LED - Lighting kit: Engine compartement and rear

Delivery by arrangement
